ALIGN MAX Grip Installation

Ideally, you’ll have a Regripping station with a vise, tape, solvent, a hook blade, a trash can or bucket, a heat gun and a towel or rag. If you don’t have a few of these things, that’s okay, we’ll note throughout the video where you can utilize other tools you might have handy.

First, you'll want a clean shaft surface to work from. Remove your old grip by slicing it with a razor or hook blade, making sure to cut away from yourself.

Then, pull off the old grip to expose the taped shaft. Next, remove the existing tape. A heat gun is the ideal tool to utilize to heat up the old tape and make it easier to remove. A rag and some solvent can help remove any glue residue on the shaft.

Tip: If you don’t have a heat gun, a hair dryer works as well.

Once the shaft is completely clean, lock it in a vise or other stable platform.

If you’re working on a table or bench, rest the club as stable as possible and line up the grip at the start as best you can.

Then, measure a length of double-sided grip tape slightly longer than the new grip.

Apply the tape, leaving a bit of excess at the end of the shaft. Be sure to smooth any wrinkles that might be felt through the finished grip.

Then, twist the excess tape together and tuck it into the end of the shaft.

Now you're ready for the new grip. Using your finger to block the vent hole at the end of the grip, pour solvent into the grip. Don’t be shy with the solvent, it will help ensure the grip is applied in one fluid push.

Roll the grip around to ensure the solvent coats the inside of the grip. Then, apply plenty of solvent to the taped shaft.

Tip: A trash can or empty bucket/container can be used to catch solvent.

Tip: A towel can also be placed on the ground to avoid a mess.

Slide the grip onto the shaft in one fluid motion. Sliding it on in one motion is ideal. With ALIGN MAX, you’ll want to ensure you put pressure on the end cap of the grip.

Once the grip is on, check that the ALIGN feature is straight and aligned properly. Alignment is important when installing any grip, but it’s crucial that ALIGN MAX is aligned properly when installed on your shaft.

Proper install ensures the grip is square in relation to the clubface. A misaligned grip could mean a closed or open clubface at address.

Next, remove your club from the vise and check to ensure the raised ridge is lined up properly in relation to the clubhead. The GOLF PRIDE logo should be directly opposite the raised ridge.

Adjust the grip until the raised ridge is lined up completely straight vertically down the grip.

Aligning the club face against a square surface will also help check if the grip is  square.

Finally, wipe off any excess solvent with a clean towel, and let the solvent dry.

Now your club is re-gripped with ALIGN MAX. You’ll want to wait around three to four hours before taking it out on the course.
